Features:
1. Flexible Mobility: Meets energy replenishment, rescue, and emergency power supply needs for operational
vehicles.
2. High-Rate Fast Charging: Suitable for fast charging of electric heavy-duty trucks, engineering machinery,
buses, etc.
3. Rapid Deployment: Industrialized mass production, avoiding hardware investments like land and
transformers.
4. Convenient Configuration: Resources can be flexibly allocated based on regional electric vehicle layout.
5. Green Power Utilization: Can be moved to power sources to utilize green electricity and curtailed power.
6. Peak Shaving & Valley Filling: Utilizes energy storage attributes to achieve grid peak shaving, valley filling,
frequency regulation, and other functions.
| General Parameters | |
| Container Dimensions (L × W × H) | 3050 × 2440 × 2590 mm |
| Battery Capacity | 500 kWh |
| Weight | 3750 kg |
| Operating Temperature Range | -25 ~ 50°C |
| Storage Temperature Range | -25 ~ 55°C |
| Operating Humidity Range | 0 ~ 95% |
| Protection Rating | IP54 |
| Suitable Altitude | >2000m (Derated use above 2000 meters) |
| Safety Protections | Leakage, Short Circuit, Overload, Overcurrent, Overheat, Phase Loss, etc. |
| Power Input Parameters | |
| AC Input Voltage | 380VAC, 250 kVA |
| Input Frequency | 45 Hz ~ 65 Hz |
| Power Factor | > 0.99 |
| Total Harmonic Current | <5% (Rated Input) |
| DC Input Voltage | 200 – 1000 V |
| DC Input Current | 320 A (0.5C) |
| Power Output Options (Customizable) | |
| Output Option 1: AC380V 250kVA (Sinusoidal Output) | Can be used as a high-power mobile AC power source |
| Output Option 2: DC Fast Charge Output (Supports V2V) | Supports charging for electric heavy-duty trucks, mining trucks |
