Product Feature:
● High luminous efficacy, high CRI
● Energy savings of up to 90% compared to halogen lamp spotlights
● CCT optional and dimmable
● Die-cast aluminum housing, ensure excellent heat dissipation
● Uniform light output and good consistency
● Anti-Glare, without flicker
● Easy and quick installation
| Product Data | |||
| Wattage | 40W | 50W | 70W |
| Installation Type | Suspended | ||
| Dimension | L1200mm x W40mm x H86mm | L1600mm*W40mm*H86mm | L2400mm*W40mm*H86mm |
| IP Rating | IP20 | ||
| Luminous Flux | 3400 lm | 4250lm | 5950lm |
| Beam Angle | / | ||
| Working Temperature | -25°C ~ 55°C | ||
| Packing Size | / | ||
| Driver Brand | Tridonic, Osram, Philips, Lifud, Euchips, Eaglerise, etc. | ||
| Input Voltage | 100-250V AC, 50/60Hz | ||
| Output Voltage | 24-40V DC | ||
| Output Current | 1000mA | ||
| Power Factor | >0.5 (Standard); >0.9 (Optional) | ||
| Efficiency | 87% @ 230V | ||
| IP Rating | IP20 | ||
| Dimmable | Non-Dimmable / Triac / 0-10V / Dali (Optional) | ||
| Free Flicker | Yes | ||
| Certificates | CE, CB, CCC, ENEC | ||
| Warranty | 3 / 5 Years | ||
| Housing Color | White / Black | ||
| Reflector Color | White / Black | ||
| Housing Material | Aluminum | ||
| LED Chip Brand | Cree / Osram / Bridgelux / Epistar, etc. | ||
| Chip Type | SMD | ||
| Color Temperature | 2700K, 3000K, 4000K, 5000K, 6000K | ||
| CRI | >82 | ||
