Energy Efficient & Cost-Saving
• 50–70% lower energy use vs. fluorescent tubes – saves 30%+ on bills
• 0-10V/DALI dimmable – Adjust brightness to match needs & save more
Sleek & Versatile Design
• Ultra-thin (0.5–1.5” depth) – Modern, seamless look for ceilings & cabinets
• Multiple lengths (2ft–8ft) + end-to-end connectors for continuous runs
Durable & Low Maintenance
• 50,000–100,000-hour lifespan – Lasts 5–10x longer than fluorescents
• IP20 waterproof options – Perfect for kitchens, garages & outdoor use
Easy Installation
• Retrofit & new-build options – Works with existing T8/T5 fixtures
• Plug-and-play or hardwired – Flexible setup in minutes
Smart & Eco-Friendly
• Motion sensor & daylight-harvesting – Auto-adjusts to save energy
• Mercury-free & recyclable – Safer for homes & the environment
| Complete Product Data | |||||
| Wattage | 20w | 30w | 40w | 50w | 60w |
| Installation Type | Suspended | ||||
| Dimension | L600mm*W55mm*H75.5mm | L900mm*W55mm*H75.5mm | L1200mm*W55mm*H75.5mm | L1500mm*W55mm*H75.5mm | L1800mm*W55mm*H75.5mm |
| IP Rating | IP20 | ||||
| Luminous Flux | 1800lm | 2700lm | 3600lm | 4500lm | 5400lm |
| Beam Angle | 110° | ||||
| Working Temperature | -25℃ ~55℃ | ||||
| Warranty | 3 Years | ||||
| Driver Data | |||||
| Driver Brand | Tridonic, Osram, Philips, Lifud, Euchips, Eaglerise, etc. | ||||
| Input Voltage | 100-250VAC 50/60hz | ||||
| Output Voltage | 27-42Vdc | ||||
| Output Current | 500mA | ||||
| Power Factor | >0.5 as standard; >0.9 optional | ||||
| Efficiently | 87% @230v | ||||
| IP Rating (Driver) | IP20 | ||||
| Dimmable | Non-Dimmable/Triac/0-10v/Dali Optional | ||||
| Free Flicker | Yes | ||||
| Certificates (Driver) | CE, CB, CCC, ENEC | ||||
| Warranty (Driver) | 3/5 Years | ||||
| Material&Housing Data | |||||
| Housing Color | White/ Black | ||||
| Housing Material | Aluminum | ||||
| Photometric Data | |||||
| LED chip brand | Cree/ Osram /Bridgelux/ Epistar etc. | ||||
| Chip Type | SMD | ||||
| Color Temperature | 2700K, 3000K, 4000K, 5000K, 6000K | ||||
| CRI | >82 | ||||
| Life time | >50000Hrs | ||||
| Lumens efficacy | 100-120lm/w | ||||
