LED Flood Light Outdoor Waterproof Stadium Lighting Adjustable Bracket SMD Led Reflector for Sports Field IP66

Give a Quick Quote：

Product Description

Features:
* 120W 240W 360W 480W 720W 960W 1200W 1440W; freely choose to meet your needs
* Light Efficiency: 160lm/W;
* available upon request Symmetrical: 20°/40°/60°/90°，Asymmetrical: 100°×140
* High-transmittance and anti-UV Frosted Polycarbonate lens; Excellent thermal management design;
* Die-casting aluminum with polyester powder coat finish;
* IP66/IK08 rating for outdoor usage;
* Easy installation and low maintenance;
* Energy savings, no UV and IR radiations, emits low heat;
* 6 years warranty optional

* Can be used in parallel with multiple modules

Specifications

Model No.	OAL-FL120	OAL-FL240	OAL-FL360	OAL-FL480	OAL-FL720	OAL-FL960	OAL-FL1200	OAL-FL1440
Power	120W	240W	360W	480W	720W	960W	1200W	1440W
Lumen Output	19,200 lm	38,400 lm	57,600 lm	76,800 lm	115,200 lm	153,600 lm	192,000 lm	230,400 lm
PC lens	SMD5050: 20°\|40°\|60°\|90°\|140°x100°; SMD3030: 60°\|90°
Luminous Efficacy	160 lm/w
CCT	3000K\|4000K\|5000K\|5700K\|6500K
CRI Ra	≥70 (Ra≥80 optional)
Input Voltage	100-277 VAC, 50Hz \| 60Hz
Housing Color	Black
Housing Material	Aluminum, PC
Operating temperature	-30°C to +50°C
Operating humidity	10% to 90% RH
Lifespan	100,000 hours
Warranty	5 years
ErP Technical Specification (25°C operating temperature)
Item Specification	Data
Efficiency In	>90%
Power Factor	PF>0.90
Energy Efficiency	Class D
Standard Deviation of Color Matching	<5
Starting Time	<0.2S
Warm-up Time to 60%	<0.5S
Lumen Maintenance at e.o.l.	>70%
Lifetime	L70/B10@100,000hours
